Special note:
The relay output is normal open position when there is no power to the
Ethernet Extender Switch. Please do not connect any power source to
this terminal to prevent shorting your power supply.
Reset Button
Press reset button for over 10 seconds to reset the Hardened Managed
Ethernet Extender Switch back to default password.
Connecting to Your Network
Cable Type & Length
It is necessary to follow the cable specifications below when connecting the Ethernet
Extender Switch to your network. Use appropriate cables that meet your speed and
cabling requirements.
Cable Specifications
Speed Connector Port Speed
Half/Full
Duplex Cable Max.
Distance
10Base-T RJ-45 10/20 Mbps 2-pair UTP/STP
Cat. 3, 4, 5 100 m
100Base-TX RJ-45 100/200 Mbps 2-pair UTP/STP
Cat. 5 100 m
Ethernet
Extender ports RJ-11 and
Terminal Block
Asymmetrical
full-duplex
59/31 Mbps
(downstream/
upstream)
Telephone line 1,900 m
Ethernet
Extender ports RJ-11 and
Terminal Block
Symmetrical
full-duplex
50 Mbps
(downstream/
upstream)
Telephone line 1,900 m
