Symmetric Mode Fixed Rate:
1. Command Mode: Interface mode
Logon to Configure Mode (Configure Terminal Mode).
Then logon to Interface mode.
vdsl1 means Ethernet Extender port 1.
The switch_a(config-if)# prompt will show on the screen.
switch_a(config)#interface vdsl1
switch_a(config-if)#
2. Usage:
Use this command to set fixed rate bandwidth settings in the symmetric
mode for Ethernet Extender port. Use the no parameter with this command
to disable fixed rate bandwidth settings for Ethernet Extender port.
3. Command Syntax:
vdsl sym-fixedrate RATE
no vdsl fixedrate
RATE
1
Set fixed rate to 1Mbps
3 Set fixed rate to 3Mbps
5 Set fixed rate to 5Mbps
10 Set fixed rate to 10Mbps
15 Set fixed rate to 15Mbps
20 Set fixed rate to 20Mbps
25 Set fixed rate to 25Mbps
30 Set fixed rate to 30Mbps
40 Set fixed rate to 40Mbps
50 Set fixed rate to 50Mbps
4. Example:
The following example specifies to set fixed rate bandwidth settings (50) in
the symmetric mode for Ethernet Extender port 1 (vdsl1):
switch_a(config)#interface vdsl1
switch_a(config-if)#vdsl sym-fixedrate 50
switch_a(config-if)#
VDSL Status
1. Command Mode: Exec mode
Logon to Exec Mode (View Mode).
The switch_a> prompt will show on the screen.
switch_a>
