bridge for the LAN. The priority values can be set only in increments of
4096.
3. Command Syntax:
bridge GROUP instance INSTANCE_ID priority BRIDGE_PRIORITY
no bridge GROUP instance INSTANCE_ID priority
GROUP <1-1> Specify the bridge-group ID.
INSTANCE_ID Specify the instance ID.
BRIDGE_PRIORITY <0-61440> Specify the bridge priority.
4. Example:
The following example sets the bridge priority (0) for an MST instance (3)
in bridge GROUP (1):
switch_a(config)#bridge 1 instance 3 priority 0
switch_a(config)#
MSTP Port Setting
Bridge-Group Instance:
1. Command Mode: Interface mode
Logon to Configure Mode (Configure Terminal Mode).
Then logon to Interface mode.
fe1 means port 1.
The switch_a(config-if)# prompt will show on the screen.
switch_a(config)#interface fe1
switch_a(config-if)#
2. Usage:
Use this command to assign a Multiple Spanning Tree instance to a port.
Use the no parameter with this command to remove the instance.
3. Command Syntax:
bridge GROUP instance INSTANCE_ID
no bridge GROUP instance INSTANCE_ID
GROUP <1-1> Specify the bridge-group ID.
INSTANCE_ID Specify the instance ID.
4. Example:
The following example assigns a Multiple Spanning Tree instance (3) to a
port (fe1) in bridge GROUP (1):
switch_a(config)#interface fe1
switch_a(config-if)#bridge-group 1 instance 3
