STP / Ring
Global Configuration, RSTP Port Setting, MSTP Properties, MSTP
Instance Setting, MSTP Port Setting, Ring Setting
Global Configuration
STP Version:
1. Command Mode: Configure mode
Logon to Configure Mode (Configure Terminal Mode).
The switch_a(config)# prompt will show on the screen.
switch_a(config)#
2. Usage:
Use this command to choose the Spanning Tree protocol, Rapid Spanning
Tree protocol, or Multiple Spanning Tree protocol on a bridge.
3. Command Syntax:
bridge GROUP protocol PROTOCOL vlan-bridge
GROUP <1-1> Bridge group name used for bridging.
PROTOCOL
ieee IEEE 802.1Q spanning-tree protocol.
mstp IEEE 802.1s multiple spanning-tree protocol.
rstp IEEE 802.1w rapid spanning-tree protocol.
4. Example:
The following example chooses the PROTOCOL (rstp) on bridge GROUP
(1):
switch_a(config)#bridge 1 protocol rstp vlan-bridge
switch_a(config)#
Multiple Spanning Tree Protocol:
1. Command Mode: Configure mode
Logon to Configure Mode (Configure Terminal Mode).
The switch_a(config)# prompt will show on the screen.
switch_a(config)#
2. Usage:
Use this command to enable the Multiple Spanning Tree protocol on a
bridge.
Use the no form of the command to disable the Multiple Spanning Tree
protocol on a bridge.
3. Command Syntax:
