Specifications
Applicable
Standards IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
Ethernet over VDSL
Switching
Method Store-and-Forward
Forwarding Rate
10Base-T
100Base-TX
Ethernet Extender
10 / 20Mbps half / full-duplex
100 / 200Mbps half / full-duplex
Asymmetic: 1/1, 14/1, 22/1, 25/2, 28/5,
35/6, 42/8, 47/14, 52/24, 59/31Mbps
Symmetric: 1, 3, 5, 10, 15, 20, 25, 30, 40,
50Mbps
Performance 14,880pps for 10Mbps
148,810pps for 100Mbps
Cable
10Base-T
100Base-TX
Ethernet Extender
2-pair UTP/STP Cat. 3, 4, 5 Up to 100m
(328ft.)
2-pair UTP/STP Cat. 5 Up to 100m (328ft.)
Telephone wires Up to 1,900m (6,232ft.)
LED Indicators Per unit – Power status (Power 1, Power 2,
Power 3)
Per port –
10/100TX: LINK/ACT, 100
RJ-11, Terminal Block: LINK/ACT
Dimensions 60mm (W) x 125mm (D) x 145mm (H)
(2.36” (W) x 4.92” (D) x 5.71” (H))
Net Weight 1.1Kg (2.42lbs.)
Power Input DC Jack: 12VDC, External AC/DC required
Terminal Block: 12-48VDC
Operating
Voltage &
Max. Current
Consumption 0.92A @ 12VDC, 0.46A @ 24VDC, 0.23A
@ 48VDC
Power
Consumption 11W Max.
Operating
Temperature -40°C to 75
℃ (-40℉ to 167℉)
Tested for functional operation @
-40
℃ to 85℃ (-40℉ to 185℉)
