Switchport mode hybrid:
1. Command Mode: Interface mode
Logon to Configure Mode (Configure Terminal Mode).
Then logon to Interface mode.
fe1 means port 1.
The switch_a(config-if)# prompt will show on the screen.
switch_a(config)#interface fe1
switch_a(config-if)#
2. Usage:
Use switchport mode hybrid command to set the switching characteristics
of the Layer-2 interface as hybrid, and classify both tagged and untagged
frames.
Use the no switchport hybrid command to reset the mode of the Layer-2
interface to access (default).
3. Command Syntax:
switchport mode hybrid
switchport mode hybrid acceptable-frame-type all/vlan-tagged
no switchport hybrid
all Set all frames can be received.
vlan-tagged Set vlan-tagged frames can only be received.
4. Example:
The following example sets the switchport mode hybrid of the interface
fe1 (port 1) and all frames to be received on interface fe1 (port 1):
switch_a(config)#interface fe1
switch_a(config-if)#switchport mode hybrid acceptable-frame-type all
switch_a(config-if)#
Switchport mode trunk:
1. Command Mode: Interface mode
Logon to Configure Mode (Configure Terminal Mode).
Then logon to Interface mode.
fe1 means port 1.
The switch_a(config-if)# prompt will show on the screen.
switch_a(config)#interface fe1
switch_a(config-if)#
2. Usage:
