MSTP Instance Setting
Bridge Instance VLAN:
1. Command Mode: MST Configuration mode
Logon to Configure Mode (Configure Terminal Mode).
Then logon to MST Configuration mode.
The switch_a(config-mst)# prompt will show on the screen.
switch_a(config)#spanning-tree mst configuration
switch_a(config-mst)#
2. Usage:
Use this command to simultaneously add multiple VLANs for the
corresponding instance of a bridge. This command can be used only after
the VLANs are defined. Use the no parameter with this command to
simultaneously remove multiple VLANs for the corresponding instance of
a bridge.
3. Command Syntax:
bridge GROUP instance INSTANCE_ID vlan VLAN_ID
no bridge GROUP instance INSTANCE_ID vlan VLAN_ID
GROUP <1-1> Specify the bridge-group ID.
INSTANCE_ID <1-15> Specify the instance ID.
VLAN_ID <1-4094> Specify multiple VLAN IDs corresponding to the
bridge instance
4. Example:
The following example associates multiple VLANs (10) and (20) to
instance (1) of bridge GROUP (1):
switch_a(config)#bridge 1 protocol mstp
switch_a(config)#spanning-tree mst configuration
switch_a(config-mst)#bridge 1 instance 1 vlan 10, 20
switch_a(config-mst)#
Bridge Instance Priority:
1. Command Mode: Configure mode
Logon to Configure Mode (Configure Terminal Mode).
The switch_a(config)# prompt will show on the screen.
switch_a(config)#
2. Usage:
Use this command to set the bridge priority for an MST instance to the
value specified. Use the no parameter with this command to restore the
default value of the bridge priority. The lower the priority of the bridge, the
better the chances are the bridge becoming a root bridge or a designated
