3. Command Syntax:
(no) vdsl asymmetric-mode
4. Example:
The following example specifies to enable the asymmetric mode for
Ethernet Extender port 1 (vdsl1):
switch_a(config)#interface vdsl1
switch_a(config-if)#vdsl asymmetric-mode
switch_a(config-if)#
Asymmetric Mode Fixed Rate:
1. Command Mode: Interface mode
Logon to Configure Mode (Configure Terminal Mode).
Then logon to Interface mode.
vdsl1 means Ethernet Extender port 1.
The switch_a(config-if)# prompt will show on the screen.
switch_a(config)#interface vdsl1
switch_a(config-if)#
2. Usage:
Use this command to set fixed rate bandwidth settings in the asymmetric
mode for Ethernet Extender port. Use the no parameter with this command
to disable fixed rate bandwidth settings for Ethernet Extender port.
3. Command Syntax:
vdsl asym-fixedrate RATE
no vdsl fixedrate
RATE
1
Set fixed rate to 1Mbps / 1Mbps
14 Set fixed rate to 14Mbps / 1Mbps
22 Set fixed rate to 22Mbps / 1Mbps
25 Set fixed rate to 25Mbps / 2Mbps
28 Set fixed rate to 28Mbps / 5Mbps
35 Set fixed rate to 35Mbps / 6Mbps
42 Set fixed rate to 42Mbps / 8Mbps
47 Set fixed rate to 47Mbps / 14Mbps
52 Set fixed rate to 52Mbps / 24Mbps
59 Set fixed rate to 59Mbps / 31Mbps
4. Example:
