switch_a(config)#bridge 1 protocol ring
switch_a(config)#
Set ring port:
1. Command Mode: Configure mode
Logon to Configure Mode (Configure Terminal Mode).
The switch_a(config)# prompt will show on the screen.
switch_a(config)#
2. Usage:
Use this command to set Ring port 1 and Ring port 2.
3. Command Syntax:
ring set-port RING_PORT_1 RING_PORT_2
RING_PORT_1 Specify the Ring port 1.
RING_PORT_2 Specify the Ring port 2.
4. Example:
The following example sets the fe1 and fe2 as Ring port 1 and Ring port 2:
switch_a(config)#ring set-port fe1 fe2
switch_a(config)#
