343
Matrox MXO2 Mini specifications
$
S/N: > 85 db
$
THDN at 1 kHz, nominal level: < 0.05%
Environmental specifications
• Minimum/maximum room operating temperature
1
: 0 to 40º C
• Minimum/maximum storage temperature: –40 to 75º C
• Maximum altitude for operation: 3,000 meters
• Maximum altitude for transport: 12,000 meters
• Operating humidity: 20 to 80% relative humidity (non-condensing)
• Storage humidity: 5 to 95% relative humidity (non-condensing)
Matrox MXO2 Mini specifications
General
•
Video formats
NTSC, PAL, NTSC-EIAJ, 1080i/p/PsF, 720p, 576p, 480p
• Regulatory compliance
$
FCC Class A, CE Mark Class A, ACMA C-Tick Mark, VCCI
$
RoHS Directive 2002/95/EC
• Dimensions
$
Length
166 mm (6.5”)
$
Width
110 mm (4.3”)
$
Height
40 mm (1.6”)
• Operating voltages and power consumption
$
Included AC/DC adapter: 100-240 V AC 50-60 Hz (5 V DC, 3 A max)
$
MXO2 Mini unit: 5-25 V DC, 2.5 mm barrel-type connector
•
9 watts power consumption
Connections
Video
• HDMI video
$
HD input and output
•
HDMI Y,Cb,Cr 4:2:2 (10-bit) / RGB (8-bit)
•
Eight channels of embedded audio
•
Standard Type A HDMI connector (19 pins)
1
This temperature range assumes that your Matrox MXO2 hardare doesn’t exceed the
maximum operating temperature as explained in
