91
Setting up Matrox device control
6 Test the audio input levels by speaking into the microphone, and watch the
levels in the meters. If needed, adjust the audio level on your source device
so that the input levels are sufficiently high but not clipping.
7 Click the Record button ( ) to prepare the sequence for recording.
8 Click the Play button ( ) to start recording your voice-over.
¦ Note During recording, there’s a slight delay in the audio preview of your
voice-over. To mute the preview, click the Mute Track button ( M ) or you can
choose to lower the track volume by dragging the Volume slider.
9 Click the Stop button ( ) to stop recording. Your voice-over will be added
to the selected audio tracks as .wav files.
Setting up Matrox device control
Matrox device control lets you control any device that supports the RS-422
SMPTE time code protocol when capturing or exporting material to tape in
Adobe Premiere Pro. To use this device control, you must connect your source
device or recorder as follows:
• Matrox MXO2, MXO2 Rack, and MXO2 LE Connect the RS-422
connector on your MXO2 hardware to the serial device control port on your
source device or recorder using an RS-422 serial cable (see
“MXO2 RS-422
serial connection” on page 18 , “MXO2 Rack RS-422 serial connection” on
page 27 , or “MXO2 LE RS-422 serial connection” on page 36 ).
• Matrox MXO2 Mini Matrox MXO2 Mini does not have an RS-422
connector. You can, however, use a suitable adapter to connect the serial
device control port on your source device or recorder to your computer. For a
list of supported device control adapters, see the Matrox MXO2 Support
section of our website at
www.matrox.com/video/support .
° To configure your Matrox device control settings:
1 Choose Edit > Preferences > Device Control .
2 From the Devices list, select Matrox RS-422 Device Control .
