324
Appendix D, Matrox MXO2 Supported Output Formats
Supported video output formats for monitoring
This section lists the formats that are supported on the MXO2 video outputs for
monitoring your video while capturing, recording, or streaming using various
applications. For descriptions of the MXO2 outputs, see
“Outputs” on page 295 .
Adobe Premiere Pro
The following table shows the formats that are supported on the MXO2 video
outputs for monitoring your captured video, based on your selected capture
format in Adobe Premiere Pro.
Matrox MXO2 output
Capture format HDMI SDI
1
Component S-Video Composite
NTSC 2 NTSC
PAL
2
PAL
486p @ 23.98 fps 480p @ 59.94 fps NTSC
720p @ 50 fps 720p @ 50 fps — —
720p @ 59.94 fps 720p @ 59.94 fps — —
1080i @ 25 fps 1080i @ 25 fps — —
1080i @ 29.97 fps 1080i @ 29.97 fps — —
1080p @ 23.98 fps 1080p/PsF @ 23.98 fps 1080PsF @ 23.98 fps — —
1080p @ 24 fps 1080p/PsF @ 24 fps
3
— — —
1080p @ 25 fps 1080p/PsF @ 25 fps 1080PsF @ 25 fps — —
1080p @ 29.97 fps 1080p/PsF @ 29.97 fps 1080PsF @ 29.97 fps
1080p @ 30 fps 1080p @ 30 fps — — —
1
SDI is not supported on Matrox MXO2 Mini.
2
NTSC and PAL are the only supported capture formats when capturing to a Matrox .m2v file.
3
1080PsF @ 24 fps is supported on the SDI output only.
