Item
Part No.
Qty.
Description Of Part
32
Ref
RIGHT SIDE WINDOW (see page 2-4
for details)
33
9108-3161
1
WEATHER STRIPPING
34
Ref
REAR WINDOW (see page 2-4 for
details)
35
9108-3159
1
WEATHER STRIPPING
36
8855-1010
1
LOCKWASHER, 5/16
37
8856-1003
4
FLAT WASHER, 5/16
38
9112-3124
4
WHIZ-LOC SCREW, 5/16-18X1/2
39
7714-3003
52
WHIZ-LOC SCREW, 5/16-18X5/8
40
9123-3012
1
BACKUP ALARM
41
8821-2224
2
SOCKET HD CAPSCREW,
5/16-18X5/8
42
9114-0001
1
COUNTERWEIGHT
43
8820-1142
4
HEX HD CAPSCREW, 1-8X4-1/2,
(hand torque to 545-595 ft.lb.)
44
8856-1011
4
WASHER, 1”
45
9020-0755
24"
WEATHER STRIPPING
46
9103-3102
1
MANUAL HOLDER
47
8832-1030
4
SELF TAPPING SCREW
48
8855-4900
4
INTERNAL TOOTH WASHER
49
9112-3153
1
SERIAL NUMBER & ATTACH PLATE
50
8834-1022
4
DRIVE SCREW
51
8820-4912
1
HEX HD CAPSCREW, 1/4-20X1,
GR5
52
8856-1107
1
FLAT WASHER
53
8852-1204
1
LOCK NUT, 1/4-20
54
9108-1475
1
HEATER COVER PLATE
55
9114-1329
1
VALVE ACCESS COVER
56
9114-3051
1
BUSHING
57
8850-1008
2
HEX NUT, 1/2 (items 57 thru 60 are
used on seat mount plate)
58
8855-1013
1
LOCKWASHER, 1/2
59
8856-1111
2
WASHER, 1/2
60
8820-1067
1
HEX HD CAPSCREW, 1/2-13X1-1/2,
GR5
61
9114-6071
1
COVER WELDMENT (route dipstick
through cab wall)
62
9114-6072
1
COVER WELDMENT
63
8820-1001
4
HEX HD CAPSCREW, 1/4-20X1/2,
GR5
Item
Part No.
Qty.
Description Of Part
9132-6001
Ref
FRAME WELDMENT
9114-6012
Ref
CAB WELDMENT
1
9108-3533
10
FENDER WASHER
2
9132-6004
1
REAR COVER WELDMENT
3
9130-3021
2
T-HANDLE
4
9132-6003
1
REAR ENGINE COVER
5
9114-1218
1
HINGE
6
9114-1253
1
SPACER BAR
7
2492-1393
1
HORN
8
2492-1394
1
HORN BRACKET
9
2492-1395
1
NUT
10
8820-1017
1
HEX HD CAPSCREW, 5/16-18X5/8,
GR5
11
9108-3173
5
RUBBER HD. SCREW BUMPER
12
9103-3320
1
TILT GAGE
13
8850-1612
5
HEX NUT, #10-24
14
9108-6162
1
TANK COVER WELDMENT
15
9020-7458
2
DRAW LATCH
16
8830-1193
8
RD.HD. MACHINE SCREW,
#10-32X1/2
17
8855-1007
13
LOCK WASHER, #10
18
8850-1613
4
HEX NUT, #10-32
19
9132-6005
1
FRONT ENGINE COVER
20
9114-3148
1
RUBBER AIR DAM
21
8368-3291
1
MIRROR
22
9020-6194
41”
TRIM-LOK
23
1440-2248
AR
ADHESIVE
24
9108-1681
1
DECK COVER
25
9108-1709
1
BELLY PAN
26
7714-3006
8
WHIZ-LOC NUT, 5/16-18
27
9103-3485
1
SEAT W/ARMREST (STD)
9112-4107
1
SLIDE ADJ. KIT (use with std. seat)
9104-3237
1
GRAMMER SEAT (OPTIONAL)
28
8850-1007
2
HEX NUT, 7/16-14
29
9103-3029
1
SEAT BELT (not used with optional
seat)
30
8820-1050
2
HEX HD CAPSCREW, 7/16-14X1,
GR5
8820-1020
4
HEX HD CAPSCREW, 5/16-18X1,
GR5 (use with optional seat only)
31
9114-1198
1
REAR CAB COVER
2-1
CHASSIS & ATTACHING PARTS
Frame Shrouding & Trim (534C-6 TURBO)
Starting Serial No. 0388043
Original Issue 7-95
Revised 3-31-97
* Changed part numbers on items 1, 25 & 49, added items 57 thru 63.
*
*
*
*
PCN 960036, 960540 & 960738-KG
