9-2
Item Part No. Qty. Description Of Part
1 Ref HYDROSTATIC DRIVE
TRANSMISSION (see page 10-18
S/N 0288568 for details)
2 8866-2242 1 SWIVEL NUT RUN TEE, 3/4 TUBE
3 8859-1207 2 O-RING (included with item 28)
4 8471-7839 1 HOSE ASSY
5 Ref TRACTION LOCK VALVE (see page
10-25 S/N 0288568 for details)
6 8866-2005 1 CONNECTOR (includes item 7)
7 8859-1204 2 O-RING
8 8471-7930 2 HOSE ASSY
9 8866-2239 1 SWIVEL NUT RUN TEE, 3/8 TUBE
10 8471-7908 1 HOSE ASSY
11 9132-3011 1 TUBE ASSY
12 8866-1362 1 HEX CAP, 1/4 TUBE
13 8471-8999 1 HOSE ASSY
14 8866-2239 1 SWIVEL NUT RUN TEE, 3/8 TUBE
15 9108-3426 1 STRAIGHT THREAD ADAPTER
(includes o-ring)
8859-1207 1 O-RING
16 Ref FRONT DRIVE MOTOR (see page
10-20 for details)
17 8866-2064 1 ELBOW, 90 DEGREES (includes
item 7)
18 Ref SOLENOID VALVE, (see page 10-14
S/N 0288777 for details)
19 8471-8644 1 HOSE ASSY
HYDRAULIC CIRCUITS
Dump Circuit (534C-6 TURBO)
Starting Serial No. 0388349
Original Issue 6-96
Revised 4-1-97
Item Part No. Qty. Description Of Part
20 8584-1150 1 CLAMP
7714-3015 1 WHIZ LOCKNUT, 3/8-16
21 8692-1327 1 TEE
22 8855-1009 2 LOCKWASHER, 1/4
23 8362-3032 1 ELBOW, 90 DEGREES
24 Ref OIL COOLER ASSY (see page 5-6
Turbo for details)
25 1 O-RING (included with item 26)
26 8325-1287 1 ADAPTER (includes item 25)
27 8471-8643 1 HOSE ASSY
28 8866-2008 2 STRAIGHT THREAD ADAPTER,
(includes item 3)
29 8866-2108 2 ELBOW, 90 DEGREES (swivel nut)
30 Ref MAIN CONTROL VALVE ASSY,
(see page 10-9 S/N 0288568 for
details)
31 8471-7832 1 HOSE ASSY
32 9108-3516 1 RESERVOIR RETURN TUBE
33 8362-3032 1 ELBOW, 90 DEGREES
34 8856-1017 2 FLAT WASHER, 1/4
35 9108-3519 1 45 DEGREE CONNECTOR
36 8471-8757 1 HOSE ASSY
37 8471-8756 1 HOSE ASSY
38 8820-1010 2 HEX HD CAPSCREW, 1/4-20X2-1/4,
GR5
39 8365-1133 1 REDUCER
40 7713-3053 1 CLAMP SET
41 7713-3052 1 COVER PLATE
PCN 960780-KG
* Changed part number on item 13.
*
