Item
Part No.
Qty.
Description Of Part
9108-4163
Ref
CARRIER ASSY, (includes all items)
1
9108-4053
1
NUT
2
9108-4054
1
WASHER
3
Ref
BRAKE ASSY, (see page 6-4 for details)
4
9108-4056
1
OIL SEAL
5
9108-4057
8
CAPSCREW
6
8
WASHER
7
9108-4058
1
THRUSTWASHER
8
9108-4059
1
PINION BEARING CONE, (outer)
9
1
PINION BEARING CAP, (outer)
10
9108-4060
1
PINION BEARING CAGE, (includes items
9 & 15)
11
9108-4061
4
NUT
12
9108-4062
4
WASHER
13
9108-4063
4
STUD
14
9108-4064
AR
.125 SPACER
9108-4065
AR
.126 SPACER
9108-4066
AR
.127 SPACER
9108-4067
AR
.128 SPACER
9108-4068
AR
.129 SPACER
9108-4069
AR
.130 SPACER
9108-4070
AR
.136 SPACER
9108-4071
AR
.142 SPACER
9108-4072
AR
.148 SPACER
9108-4073
AR
.154 SPACER
9108-4074
AR
.158 SPACER
15
1
PINION BEARING CUP
16
9108-4059
1
PINION BEARING CONE
17
1
PINION
18
9108-4075
AR
.003 SHIM
9108-4076
AR
.005 SHIM
9108-4077
AR
.010 SHIM
19
9108-4078
1
REAR PINION BEARING
20
9108-4079
1
REAR PINION LOCKRING
21
9108-4080
1
DIFFERENTIAL CARRIER ASSY
22
8307-3699
1
PLUG
23
9108-4081
4
THRUSTWASHER
24
9108-4082
4
PINION
25
9108-4083
1
SPIDER
Item
Part No.
Qty.
Description Of Part
26
9108-4084
2
GEAR
27
9108-4085
2
THRUSTWASHER
28
9108-4086
2
CLUTCH SPACER
29
9108-4087
2
CLUTCH DISC
30
9108-4088
AR
.005 SHIM
9108-4089
AR
.010 SHIM
9108-4090
AR
.013 SHIM
9108-4091
AR
.015 SHIM
31
9108-4092
16
CLUTCH DISC
32
9108-4093
1
GEAR ASSY, (includes item 17)
33
9108-4094
1
FLANGE HALF DIFF. CASE ASSY
(includes items 1, 19, 20, 23 thru 31,
33 & 42 thru 48)
9108-4095
1
DIFFERENTIAL CASE ASSY, (includes
items 23 thru 31, & 45 thru 48)
34
9108-4097
2
BEARING CONE
35
9108-4098
2
BEARING CUP
36
9108-4099
2
ADJUSTING RING
37
4
DOWEL PIN
38
4
WASHER
39
4
CAPSCREW
40
8348-3441
2
COTTER PIN
41
2
BEARING CAP, (includes item 37)
42
9108-4101
12
CAPSCREW
43
9108-4102
12
WASHER
44
7710-4297
12
NUT
45
9108-4103
14
CLUTCH DISC
46
1
PLAIN HALF DIFF. CASE
47
9108-4104
12
CAPSCREW
48
9108-4102
12
WASHER
49
9108-4360
1
SPLINED SHAFT
50
9108-4354
1
INNER SPLINE ADAPTER
51
9108-4355
1
OUTER COLLAR
52
9108-4356
1
EXTERNAL SNAP RING
53
9108-4357
1
INTERNAL SNAP RING
NOTE: ONLY ITEMS WITH PART
NUMBERS ARE AVAILABLE
FOR SERVICE
DRIVE TRAIN
(9108-4163) Front Axle Differential Carrier
Starting Serial No. 0188002
Original Issue 1-90
Revised 6-27-07
6-3
JM
*
* Revised part number on item 40.
