Item
Part No.
Qty.
Description Of Part
9112-5043
Ref
AUXILIARY HYDRAULICS ASSY
(includes all items on both pages)
1
Ref
5 BUTTON HANDLE (see page 13-44
for details)
2
8850-1112
1
HEX JAM NUT, 3/4-16
3
9112-6024
1
LEVER WELDMENT
4
9112-6025
1
LEVER BRACKET
5
8820-1036
4
HEX HD CAPSCREW, 3/8-16 x 1 1/4
6
8850-1006
4
HEX NUT, 3/8-16
7
8855-1011
4
LOCKWASHER, 3/8
8
9112-6027
1
PIN WELDMENT
9
9108-3136
2
BUSHING
10
8820-1018
2
HEX HD CAPSCREW, 5/16-18 x 3/4
11
8855-1010
2
LOCKWASHER, 5/16
12
9112-3051
1
MOLDED RUBBER BUSHING
13
1440-2248
AR
3M ADHESIVE
14
9002-8956
1
CONNECTOR BODY
15
9002-8958
6
TERMINAL
16
9002-8978
1
CABLE CLAMP
17
9040-3396
1
AUXILIARY WIRING HARNESS
18
9002-7187
14
TIE WRAP
19
8203-3993
12"
LOOM, 5/16 I.D.
Item
Part No.
Qty.
Description Of Part
20
9020-7464
2
CUSHION CLAMP, 3/4
21
8471-8040
2
HOSE ASSY
22
8866-1065
2
UNION, 1/2 TUBE
23
8850-1005
1
HEX NUT, 5/16
24
9103-3394
1
AUXILIARY CONTROL DECAL
25
8882-1002
1
YOKE END
26
8863-3001
1
CLEVIS PIN
27
8863-1302
1
COTTER PIN, 1/16 x 3/4
28
8850-1404
1
HEX JAM NUT, 1/4-28
29
9112-6023
1
CABLE BRACKET WELDMENT
30
9112-3050
1
PUSH-PULL CABLE
31
9108-3310
2
ELBOW, 90 DEGREE (includes item 32)
32
8859-1206
2
O-RING
33
9002-8662
2
WAVE BEND WASHER
34
9112-3062
1
CABLE ADAPTER BONNET
35
9108-3343
2
ELBOW, 90 DEGREES
36
8866-1348
2
TUBE END REDUCER, 5/8 TO 3/4
37
8866-1407
2
NUT, 5/8
38
8471-8040
2
HOSE ASSY
39
9002-8968
1
CONNECTOR
40
9103-3391
1
INSULATED RING TERMINAL
41
8698-3193
1
MALE BULLET
OPTIONAL EQUIPMENT
(9112-5043) Auxiliary Hydraulic Assembly w/Electric
Starting Serial No. 0288777
Original Issue 10-95
Revised 6-25-99
13-7
KG
* Added part breakdown and see page for 5-button handle.
*
