Gradall 534C-6 Parts Manual - Manual (Page 276)

VIEW A-A
A
A
Item Part No. Qty. Description Of Part
9108-4283 1 COMMON DECAL KIT - WHITE
(includes all items except 11,
18 & 19, on page 12-2, and all
standard items on page 12-3, except
items 8 thru 11, 13, 14, 15 & 17)
1 9108-3494 1 BATTERY WARNING
2 9108-3497 1 JUMP START WARNING
3 9108-3510 1 FUEL WARNING PLATE
4 9108-3509 1 HYDRAULIC OIL PLATE
5 9108-3492 2 OIL WARNING DECAL
6 9103-3011 1 WARNING DECAL (located on side
of tank cover)
7 7734-3018 1 WARNING DECAL (located on side
of rear cover weldment)
8 9104-3210 1 COOLING SYS. CAUTION DECAL
9 8360-1011 1 ACCIDENT PREVENTION DECAL
10 9104-3215 1 LIFTING PERSONNEL DECAL
11 9132-3001 1 SERVICE INSTRUCTION DECAL
12 9130-3047 1 BOOM OPERATION DECAL
13 9108-3317 1 TILT DECAL
14 9108-3318 1 SWAY DECAL
Item Part No. Qty. Description Of Part
15 9104-3209 2 PINCH POINT DECAL
16 7733-3027 1 MADE IN USA DECAL
17 9100-3030 1 PATENT DECAL
18 9112-3110 1 SERIAL NUMBER & ATTACHMENT
PLATE
19 8834-1022 4 DRIVE SCREW
20 9106-3047 1 WARNING DECAL
21 9104-3211 1 RIDERS WARNING DECAL
22 9114-3120 1 INSTRUMENT PANEL DECAL
23 9114-3182 1 PARK BRAKE DECAL
24 9108-3314 1 TRACTION DECAL
25 9108-3428 1 FORWARD - REVERSE DECAL
(supplied with reversing master
switch)
26 9112-3117 1 CAPACITY CHART
27 7702-3007 1 BATTERY INSTRUCTION DECAL,
(not shown)
28 8364-1675 1 GRADALL DECAL (not shown)
29 9108-3324 1 SERVICE DECAL (not shown, this
decal does not apply, order 9132-3001
534C-6T service decal)
MISCELLANEOUS
Frame Decals (534C-6 TURBO)
Starting Serial No. 0388043 thru 0388246
Original Issue 9-95
Revised 2-5-98
JH 12-2
NOTE: USE 1440-4645 BOESHIELD PROTECTANT (12 OZ. SPRAY) ON ANY EXPOSED METAL
*Revised serial number due to addition of new design.
