MaximIntegrated 4-1
MAX31782 User’s Guide
Revision 0; 8/11
The MAX31782 has six peripheral register modules, Modules 0 through 5 . This section describes the MAX31782’s
peripheral registers .
Table 4-1 shows the MAX31782 peripheral register map . Table 4-2 explains peripheral register bit
functions . Detailed peripheral register bit descriptions and default values appear in the corresponding function block
description section .
Table4-1.PeripheralRegisterMap
SECTION 4: PERIPHERAL REGISTER MODULES
INDEX M0 M1 M2 M3 M4 M5
00h PO2 I2CBUF_M I2CBUF_S PWMC0 PWMC2 MCNT
01h PO1 I2CST_M I2CST_S PWMR0 PWMR2 MA
02h I2CIE_M I2CIE_S PWMC1 PWMC3 MB
03h MIIR0 PO6 MIIR2 PWMR1 PWMR3 MC2
04h MIIR1 SMBUS MC1
05h TACHR0 TACHR2 MC0
06h TB0C EIF6 ADST MC1R
07h TB0R EIE6 ADADDR TACHR1 TACHR3 MC0R
08h PI2 PI6 ADCN PWMV0 PWMV2 PWMV4
09h PI1 SVM ADDATA PWMCN0 PWMCN2 PWMCN4
0Ah PWMV1 PWMV3 PWMC4
0Bh TB0V PWMCN1 PWMCN3 PWMR4
0Ch I2CCN_M I2CCN_S TACHV0 TACHV2 TACHV4
0Dh TB0CN I2CCK_M I2CCK_S TACHCN0 TACHCN2 TACHCN4
0Eh I2CTO_M I2CTO_S TACHV1 TACHV3
0Fh I2CSLA_M I2CSLA_S TACHCN1 TACHCN3 TACHR4
10h PD2 EIES6 MIIR3 MIIR4
11h PD1 TACHR5
12h PD6 TACHV5
13h TACHCN5
14h PWMC5
15h I2C_SPB PWMR5
16h ETS DEV_NUM PWMV5
17h ADCG1 PWMCN5
18h ADCG5 ICDT0 MIIR5
19h ADVOFF ICDT1
1Ah TOEX ICDC
1Bh ICDF
1Ch ICDB
1Dh ICDA
1Eh ICDD
1Fh
