15.2.4WatchdogTimerControlRegister(WDCN)
*Bits 5, 4, 3 and 0 are cleared to 0 on all forms of reset; for others, see individual bit descriptions.
Bit 7 6 5 4 3 2 1 0
Name POR EWDI WD1 WD0 WDIF WTRF EWT RWT
Reset s* s* 0 0 0 s* s* 0
Access rw rw rw rw rw rw rw rw
BIT NAME DESCRIPTION
7 POR
Power-On-Reset Flag . This bit is set to 1 whenever a power-on/brownout reset occurs . It is unaffected by
other forms of reset . This bit can be checked by software following a reset to determine if a power-on/
brownout reset occurred . It should always be cleared by software following a reset to ensure that the
sources of following resets can be determined correctly .
6 EWDI
Enable Watchdog Timer Interrupt . If this bit is set to 1, an interrupt request can be generated when the
WDIF bit is set to 1 by any means . If this bit is cleared to 0, no interrupt occurs when WDIF is set to 1;
however, it does not stop the watchdog timer or prevent watchdog resets from occurring if EWT = 1 . If
EWT = 0 and EWDI = 0, the watchdog timer is stopped . If the watchdog timer is stopped (EWT = 0 and
EWDI = 0), setting the EWDI bit resets the watchdog interval and reset counter and enables the watchdog
timer . This bit is cleared to 0 by power-on reset and is unaffected by other forms of reset .
5:4 WD[1:0]
Watchdog Timer Interval Control Bits . These bits determine the watchdog timeout interval . The timeout
interval is set in terms of system clocks . Modifying the watchdog interval automatically resets the watch-
dog timer unless the 512 system clock reset counter is already in progress, in which case, changing the
WD[1:0] bits does not affect the watchdog timer or reset counter .
WD1 WD0 CLOCKSUNTILINTERRUPT CLOCKSUNTILRESET
0 0 2 12 2 12 + 512
0 1 2 15 2 15 + 512
1 0 2 18 2 18 + 512
1 1 2 21 2 21 + 512
3 WDIF
Watchdog Interrupt Flag . This bit is set to 1 when the watchdog timer interval has elapsed or can be set to
1 by user software . When WDIF = 1, an interrupt request occurs if the watchdog interrupt has been enabled
(EWDI = 1) and not otherwise masked or prevented by an interrupt already in service (i .e ., IGE = 1, IMS = 1,
and INS = 0 must be true for the interrupt to occur) . This bit should be cleared by software before exiting the
interrupt service routine to avoid repeated interrupts . Furthermore, if the watchdog reset has been enabled
(EWT = 1), a reset is scheduled to occur 512 system clock cycles following setting of the WDIF bit .
2 WTRF
Watchdog Timer Reset Flag . This bit is set to 1 when the watchdog resets the processor . Software can
check this bit following a reset to determine if the watchdog was the source of the reset . Setting this bit
to 1 in software does not cause a watchdog reset . This bit is cleared by power-on reset only and is unaf-
fected by other forms of reset . It should also be cleared by software following any reset so that the source
of the next reset can be correctly determined by software . This bit is only set to 1 when a watchdog reset
actually occurs . If EWT is cleared to 0 when the watchdog timer elapses, this bit is not set .
1 EWT
Enable Watchdog Timer Reset . If this bit is set to 1 when the watchdog timer elapses, the watchdog resets
the MAX31782 512 system clock cycles later unless action is taken to disable the reset event . Clearing this
bit to 0 prevents a watchdog reset from occurring but does not stop the watchdog timer or prevent watch-
dog interrupts from occurring if EWDI = 1 . If EWT = 0 and EWDI = 0, the watchdog timer is stopped . If the
watchdog timer is stopped (EWT = 0 and EWDI = 0), setting the EWT bit resets the watchdog interval and
reset counter and enables the watchdog timer . This bit is cleared on power-on reset and is unaffected by
other forms of reset .
0 RWT
Reset Watchdog Timer . Setting this bit to 1 resets the watchdog timer count . If watchdog interrupt and/or
reset modes are enabled, the software must set this bit to 1 before the watchdog timer elapses to prevent
an interrupt or reset from occurring . This bit always returns 0 when read .
