High-Speed Microcontroller User’s Guide: DS80C390 Supplement
88 of 158
CAN 1 MESSAGE CENTER 9 CONTROL REGISTER (C1M9C)
7 6 5 4 3 2 1 0
SFR F6h MSRDY ETI ERI INTRQ EXTRQ MTRQ ROW/TIH DTUP
RW-0 RW-0 RW-0 RW-0 RC-0 R*-0 R*-0 R*-0
R = Unrestricted Read, C = Clear Only, * = See description below, -n = Value after Reset
C1M9C
Bits 7-0 Operation of the bits in this register are identical to those found in the CAN 1
Message One Control Register (C1M1C;ABh). Please consult the description
of that register for more information.
CAN 1 MESSAGE CENTER 10 CONTROL REGISTER (C1M10C)
7 6 5 4 3 2 1 0
SFR F7h MSRDY ETI ERI INTRQ EXTRQ MTRQ ROW/TIH DTUP
RW-0 RW-0 RW-0 RW-0 RC-0 R*-0 R*-0 R*-0
R = Unrestricted Read, C = Clear Only, * = See description below, -n = Value after Reset
C1M10C
Bits 7-0 Operation of the bits in this register are identical to those found in the CAN 1
Message One Control Register (C1M1C;ABh). Please consult the description
of that register for more information.
EXTENDED INTERRUPT PRIORITY (EIP)
7 6 5 4 3 2 1 0
SFR F8h CANBIP C0IP C1IP PWDI PX5 PX4 PX3 PX2
RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0
R = Unrestricted Read, W = Unrestricted Write, -n = Value after Reset
CANBIP
Bit 7 CAN 0/1 Activity Interrupt Priority. This bit controls the priority of the CAN 0/1
Activity Interrupt
0 = The CAN 0/1 Activity Interrupt is a low priority interrupt.
1 = The CAN 0/1 Activity Interrupt is a high priority interrupt.
C0IP
Bit 6 CAN 0 Interrupt Priority. This bit controls the priority of the CAN 0 Interrupt
0 = The CAN 0 Interrupt is a low priority interrupt.
1 = The CAN 0 Interrupt is a high priority interrupt.
C1IP
Bit 5 CAN 1 Interrupt Priority. This bit controls the priority of the CAN 1 Interrupt
0 = The CAN 1 Interrupt is a low priority interrupt.
1 = The CAN 1 Interrupt is a high priority interrupt.
PWDI
Bit 4 Interrupt Priority. This bit controls the priority of the watchdog interrupt.
0 = The watchdog interrupt is a low priority interrupt.
1 = The watchdog interrupt is a high priority interrupt.
PX5
Bit 3 External Interrupt 5 Priority. This bit controls the priority of external interrupt 5.
0 = External interrupt 5 is a low priority interrupt.
