High-Speed Microcontroller User’s Guide: DS80C390 Supplement
122 of 158
MOVX MESSAGE CENTERS FOR CAN 1
CAN 1 CONTROL/STATUS/MASK REGISTERS
Register 7 6 5 4 3 2 1 0
MOVX Data
Address 1
C1MID0 MID07 MID06 MID05 MID04 MID03 MID02 MID01 MID00 xxxx00h
C1MA0 M0AA7 M0AA6 M0AA5 M0AA4 M0AA3 M0AA2 M0AA1 M0AA0 xxxx01h
C1MID1 MID17 MID16 MID15 MID14 MID13 MID12 MID11 MID10 xxxx02h
C1MA1 M1AA7 M1AA6 M1AA5 M1AA4 M1AA3 M1AA2 M1AA1 M1AA0 xxxx03h
C1BT0 SJW1 SJW0 BPR5 BPR4 BPR3 BPR2 BPR1 BPR0 xxxx04h
C1BT1 SMP TSEG26 TSEG25 TSEG24 TSEG13 TSEG12 TSEG11 TSEG10 xxxx05h
C1SGM0 ID28 ID27 ID26 ID25 ID24 ID23 ID22 ID21 xxxx06h
C1SGM1
ID20 ID19 ID18 0 0 0 0 0 xxxx07h
C1EGM0 ID28 ID27 ID26 ID25 ID24 ID23 ID22 ID21 xxxx08h
C1EGM1 ID20 ID19 ID18 ID17 ID16 ID15 ID14 ID13 xxxx09h
C1EGM2 ID12 ID11 ID10 ID9 ID8 ID7 ID6 ID5 xxxx0Ah
C1EGM3 ID4 ID3 ID2 ID1 ID0 0 0 0
xxxx0Bh
C1M15M0 ID28 ID27 ID26 ID25 ID24 ID23 ID22 ID21 xxxx0Ch
C1M15M1 ID20 ID19 ID18 ID17 ID16 ID15 ID14 ID13 xxxx0Dh
C1M15M2 ID12 ID11 ID10 ID9 ID8 ID7 ID6 ID5 xxxx0Eh
C1M15M3
ID4 ID3 ID2 ID1 ID0 0 0 0 xxxx0Fh
CAN 1 MESSAGE CENTER 1
Reserved xxxx10h - 11h
C1M1AR0 CAN 1 MESSAGE 1 ARBITRATION REGISTER 0 xxxx12h
C1M1AR1 CAN 1 MESSAGE 1 ARBITRATION REGISTER 1 xxxx13h
C1M1AR2 CAN 1 MESSAGE 1 ARBITRATION REGISTER 2 xxxx14h
C1M1AR3 CAN 1 MESSAGE 1 ARBITRATION REGISTER 3 WTOE xxxx15h
C1M1F DTBYC3 DTBYC2 DTBYC1 DTBYC0
T/ R EX/ ST MEME MDME
xxxx16h
C1M1D0-7 CAN 1 MESSAGE 1 DATA BYTES 0 - 7 xxxx17h - 1Eh
Reserved xxxx1Fh
