44 TruVision DVR 42 User Manual
• Manually change the video output format (PAL/NTSC)
• Change the time out period after which the display reverts to showing live
view
• Enable/disable the transparency of the menus on screen
• Enable/disable whether the status icons appear on screen
See Figure 19 below and Figure 20 on page 45.
The changes are immediately implemented once Apply is clicked to save the
settings.
Figure 19: Monitor setup window: General Settings
Table 11: Description of the Monitor setup window: General Settings
Option Description
1. Language Change the language of the system.
Select the desired language from the drop-down list and click
Apply . The language displayed changes immediately.
2. Device Name Define the DVR name. The default name is TVR 42.
Click the edit box and enter the new name from the soft keyboard.
3. Device Address The device number to use for the DVR when programming the
remote control. The default value is 255.
4. Zone ID Each DVR in a daisy chain must have a unique zone ID so that it
can be controlled by a KTD-405 keypad.
The default value is 1.
5. VGA Resolution Define the VGA resolution.
Select one of the options from the drop-down list and click Apply .
The selected resolution must be the same as that of the monitor.
6. HDMI Resolution Define the HDMI resolution.
Select one of the options from the drop-down list and click Apply .
The selected resolution must be the same as that of the monitor.
7. Password Required Define whether a login password is required.
Check the box to enable/disable and click Apply .
