26 TruVision DVR 42 User Manual
Item Name Description
8. Status LEDs HDD: A steady green light indicates that the recorder is
accessing the HDD in read or write mode. A steady red
indicates a HDD failure.
Network: A steady green light indicates that the
recorder is currently connected to a network. No light
indicates that it is not connected to a network.
Internal: A steady green light indicates that the recorder
is recording video or audio. No light means that it is not
recording. A steady red light means that there has been
an internal health failure.
Alarm: A steady red light indicates that there is a sensor
Alarm In or other alarm such as motion detection or
tampering. A steady green light means there is no
alarm.
9. Alarm button Use to manually acknowledge an alarm. In live view
mode, use it to call the alarm recipient.
10. Alarm indicator bar Blinking red indicates that there is an alarm.
11. Joystick Use to select options in a menu and to control playback.
Press for Enter. The LED arrows are lit when the jog is
active.
Live view mode: Press Enter to enter/exit PTZ mode.
Menu mode: Move the joystick left/right and up/down to
position cursor in the menu window. Press for Enter.
Playback mode: Move the joystick left/right to slow
down or speed up playback. Move it up/down to jump
forwards or backwards by 30 seconds. Press Enter to
stop/start playback.
PTZ mode:
Move the joystick to control the movement of the PTZ
dome camera. Move the joystick left/right to slow down
or speed up PTZ. Move it up/down to jump forwards or
backwards by 30 seconds.
12. PTZ buttons Zoom: Use + and – for digital zoom.
Preset: Call up preprogrammed preset positions.
Tour: Call up preprogrammed shadow tours.
13. Playback buttons Reverse: In live view mode, press to jump back to
the oldest available video and start play back. In
playback mode, press to play back video in reverse. In
snapshot playback mode, view snapshots in the reverse
direction.
Pause: In live view mode, freeze the last image of
the live video. In playback mode, pause playback.
Forward: In live view mode, press to start all-day
playback of the currently selected camera. If you are in
multiview format, only the camera shown in the top-left
corner of the multiview is played back
Live: Switch to live view mode.
Replay: Replay the current file in playback Starts at the
beginning of the file.
