TruVision DVR 42 User Manual 115
Option Description
Enable server
authentication Check the box if your mail server requires authentication, and
enter the login user name and password.
SMTP server Enter the SMTP server’s IP address.
SMTP port Enter the SMTP port. The default TCP/IP port for SMTP is 25.
Enable SSL Check the box to enable SSL if it is required by the SMTP
server. This feature is optional.
Sender Enter the name of the sender of the e-mail.
Sender’s address Enter the sender’s e-mail address.
Select receivers Select an e-mail recipient. Up to three receivers can be selected.
Receiver Enter the name of the receiver of the e-mail.
Receiver’s address Enter the e-mail address of the receiver.
Enable attached snapshot Check the Attach JPEG File box if you want to send an e-mail
with attached alarm images.
Interval Select an interval range in the Interval box.
The interval range represents the time range in between the
alarm images being sent. For example, if you set the interval
range at two seconds, the second alarm image will be sent two
seconds after the first alarm image
3. Click Test to the test e-mail settings.
Note: We recommend that you test the e-mail settings after entering values in
the e-mail window.
4. Click Apply to save the settings.
5. Click Back to return to live view or to continue to configure.
Configuring UPnP
The DVR supports UPnP (Universal Plug and Play). This feature lets the DVR
automatically configure its own port forwarding, if this feature is also enabled in
the router.
You can select one of two methods to set up UPnP:
Automatic mapped type: The DVR automatically uses the free ports available
that were set up in the Network Settings menu.
Manual mapped type: You enter the particular external port settings and IP
addresses required to connect to the desired router (see Figure 38 Error!
Bookmark not defined.).
To enable UPnP:
1. Connect the DVR to the router.
Note: The router must support UPnP and this option must be enabled.
