TruVision DVR 42 User Manual 29
Item Description
7. Menu Activate the main menu.
8. Seq Start /stop sequencing.
9. , , , In Menu mode: Use left or right arrow buttons to select and up or down
arrow buttons to edit entry.
In PTZ mode: Use to control PTZ.
In Playback mode: Use to control playback speed.
10. OK Confirm selection.
11. Zoom + and - Use to control zoom of camera lens.
12. Preset Enter preprogrammed three-digit code to call up a preset.
13. Tour Enter preprogrammed three-digit code to call up shadow tour.
14. Focus + and - Use to control focus of camera lens.
15. Playback control Use to control playback (Rewind, Pause, Play, and Fast Forward).
16. Search Open the Search menu.
17. Replay Replay the selected file from the beginning.
18. Eject Eject the CD or DVD disk.
19. Archive Press once to enter quick archive mode. Press twice to start archiving.
Aim the remote control at the IR receiver located at the front of the unit to test
operation.
To connect the remote control to the TVR 42:
1. Press the Menu button on the front panel or right-click the mouse and select
the Menu button. The main menu window appears.
2. Click Display Mode Settings > Monitor .
3. Check the device address value. The default value is 255. This device
address is valid for all IR controls.
4. On the remote control press the Device button.
5. Enter the device address value. It must be the same as that on the TVR 42.
6. Press OK on the remote control.
To place batteries into the IR remote control:
1. Remove the battery cover.
2. Insert the batte
ries. Make sure that the positive (+) and negative (−) poles are
correctly placed.
3. Replace the battery cover.
Troubleshooting the remote control:
If the IR remote control is not functioning properly, perform the following tests:
