Table C-6: Twelve C-Mores, Six ECS/SmartPlate, Four Modulex and Two ACS/BMS II
Equip Point Name Name
Read
Only
BACnet
Type:ID N2
Type
N2
ID
Lon SNVT
NAME
Lon SNVT
Lon
Direction
ModBus/
Unit
Address
13
07-Display Code dispcode_13  AV:7
data
float
7 nvoDispCode13 inc count (9)
Output (non-
polled)
30001/13
13
08-Unit Status unitstat_13  AV:8
data
float
8 nvoUnitStat13 inc count (9)
Output (non-
polled)
30002/13
13
09-Run Cycles runcycles_13  AV:9
data
float
9 nvoRunCycles13 51
Output (non-
polled)
30012-30013/13
13
10-Run Hours runhours_13  AV:10
data
float
10 nvoRunHours13 51
Output (non-
polled)
30014-30015/13
C-More Addr 14
14
01-Fire Rate Out boilerstate_14  AV:11
data
float
11 nvoBlrState14 inc count (9) Output (non-polled) 30009/14
14
02-Active Setpoint effectsetpt_14  AV:12
data
float
12 nvoEffSetpt14 inc count (9) Output (non-polled) 30017/14
14 03-Net Remote
Setpt
setpt_14 AV:13
data
float
13 nviSetpt14 inc count (9) Input (non-polling) 40001/14
14
05-Fire Rate In boilerload_14  AV:15
data
float
15 nvoBlrLoa14 inc count (9) Output (non-polled) 30018/14
14
06-Outlet Temp
localsuptemp_1
4

AV:16
data
float
16 nvoLocSupTmp14 inc count (9) Output (non-polled) 30003/14
14
07-Display Code dispcode_14

AV:17
data
float
17 nvoDispCode14 inc count (9) Output (non-polled) 30001/14
14 08-Unit Status unitstat_14  AV:18 data
float 18
nvoUnitStat14 inc count (9) Output (non-polled) 30002/14
14
09-Run Cycles runcycles_14  AV:19
data
float
19 nvoRunCycles14 51 Output (non-polled)
30012-
30013/14
14
10-Run Hours runhours_14  AV:20
data
float
20 nvoRunHours14 51 Output (non-polled)
30014-
30015/14
C-More Addr 15
15
01-Fire Rate Out boilerstate_15  AV:21
data
float
21 nvoBlrState15 inc count (9) Output (non-polled) 30009/15
15
02-Active Setpoint effectsetpt_15  AV:22
data
float
22 nvoEffSetpt15 inc count (9) Output (non-polled) 30017/15
15 03-Net Remote
Setpt
setpt_15 AV:23
data
float
23 nviSetpt15 inc count (9) Input (non-polling) 40001/15
