AERCO ProtoNode Gateway
User Manual
OMM-0080_0H AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 61 of 126
GF-129 Ph.: 800-526-0288 11/06/2014
Net Remote Setpoint 3xx14 Input X13 °F (40 to 200)
Run Cycles Upper 16 bits 3xx15 Input X14 0 to 65535 (see note)
Run Cycles Lower 16 bits 3xx16 Input X15 0 to 65535 (see note)
Run Hours Upper 16 bits 3xx17 Input X16 0 to 65535 (see note)
Run Hours Lower 16 bits 3xx18 Input X17 0 to 65535 (see note)
Oxygen Level 3xx19 Input X18 % (0 to 25)
IMPORTANT
For WHM and BST, use the SSD profiles.
NOTE
For WHM Heater or BST Boiler
#1, ‘x’ = 03
#2, ‘x’ = 04
#3, ‘x’ = 05
#4, ‘x’ = 06
#5, ‘x’ = 07
#6, ‘x’ = 08
#7, ‘x’ = 09
#8, ‘x’ = 10
Time
Time is expressed in minutes since midnight. For example, 360 equals 6 AM.
Run Cycles and Run Hours
Example:
Run Cycles = Run Cycles Upper 16 bits * 65536 + Run Cycles Lower 16 bits
Run Hours = Run Hours Upper 16 bits * 65536 + Run Hours Lower 16 bits
Unit Types for BST
1=KC Boiler LN, 2=BMK Boiler Std, 3=BMK Blr Std Dual, 4=BMK Boiler LN,
5=BMK Blr LN Dual
Unit Types for WHM
1=KC Boiler LN, 2=BMK Boiler Std, 3=BMK Blr Std Dual, 4=BMK Boiler LN,
5=BMK Blr LN Dual, 6=KC Water Heater, 7=KC Wtr Heater LN, 8=Innovation
WH
Unit Sizes
1=600 MBH, 2=800 MBH, 3=1060 MBH, 4=1350 MBH, 5=600 MBH, 6=800
MBH, 7=1060 MBH, 8=1350 MBH, 9=500 MBH, 10=750 MBH, 11=1000 MBH,
12=1.5 MBTU, 13=1500 MBH, 14=2.0 MBTU, 15=2000 MBH, 16=2500 MBH,
17=3.0 MBTU, 18=3000 MBH, 19=4000 MBH, 20=5000 MBH, 21=6000 MBH
