AERCO ProtoNode Gateway
User Manual
OMM-0080_0H AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 63 of 126
GF-129 Ph.: 800-526-0288 11/06/2014
Table C-1: Four C-Mores and One ACS/BMS II/BMS
Equip Point Name Name
Read
Only
BACnet
Type:ID
N2 Type
N2
ID
Lon SNVT
NAME
Lon SNVT Lon Direction
ModBus/
Unit Addr.
2 10-Run Hours runhours_2  AV:45 data float 20 nvoRunHours2 51 Output (non-polled) 30014-
30015/2
2 11-Oxygen o2level_2  AV:162 data float 162 nvoO2Lev2 inc count (9) Output (non-polled)
30010/2
2 12-Exhaust Temp exhtemp_2  AV:182 data float 182 nvoExhTmp2 inc count (9) Output (non-polled)
30007/2
Blr Addr 3
3 01-Fire Rate Out boilerstate_3  AV:54 data float 21 nvoBlrState3 inc count (9) Output (non-polled)
30009/3
3 02-Active Setpoint effectsetpt_3  AV:55 data float 22 nvoEffSetpt3 inc count (9) Output (non-polled)
30017/3
3 03-Net Remote Setpt setpt_3 AV:56 data float 23 nviSetpt3 inc count (9) Input (non-polling)
40001/3
3 05-Fire Rate In boilerload_3  AV:60 data float 25 nvoBlrLoad3 inc count (9) Output (non-polled)
30018/3
3 06-Outlet Temp localsuptemp_3  AV:61 data float 26 nvoLocSupTmp3 inc count (9) Output (non-polled)
30003/3
3 07-Display Code dispcode_3  AV:62 data float 27 nvoDispCode3 inc count (9) Output (non-polled)
30001/3
3 08-Unit Status unitstat_3  AV:63 data float 28 nvoUnitStat3 inc count (9) Output (non-polled)
30002/3
3 09-Run Cycles runcycles_3  AV:58 data float 29 nvoRunCycles3 51 Output (non-polled) 30012-
30013/3
3 10-Run Hours runhours_3  AV:59 data float 30 nvoRunHours3 51 Output (non-polled) 30014-
30015/3
3 11-Oxygen o2level_3  AV:163 data float 163 nvoO2Lev3 inc count (9) Output (non-polled)
30010/3
3 12-Exhaust Temp exhtemp_3  AV:183 data float 183 nvoExhTmp3 inc count (9) Output (non-polled)
30007/3
Blr Addr 4
4 01-Fire Rate Out boilerstate_4  AV:70 data float 31 nvoBlrState4 inc count (9) Output (non-polled)
30009/4
4 02-Active Setpoint effectsetpt_4  AV:71 data float 32 nvoEffSetpt4 inc count (9) Output (non-polled)
30017/4
4 03-Net Remote Setpt setpt_4 AV:72 data float 33 nviSetpt4 inc count (9) Input (non-polling) 40001/4
4 05-Fire Rate In boilerload_4  AV:73 data float 35 nvoBlrLoad4 inc count (9) Output (non-polled)
30018/4
4 06-Outlet Temp localsuptemp_4  AV:65 data float 36 nvoLocSupTmp4 inc count (9) Output (non-polled)
30003/4
4 07-Display Code dispcode_4  AV:66 data float 37 nvoDispCode4 inc count (9) Output (non-polled)
30001/4
4 08-Unit Status unitstat_4  AV:67 data float 38 nvoUnitStat4 inc count (9) Output (non-polled)
30002/4
4 09-Run Cycles runcycles_4  AV:68 data float 39 nvoRunCycles4 51 Output (non-polled) 30012-
30013/4
