Table C-6: Twelve C-Mores, Six ECS/SmartPlate, Four Modulex and Two ACS/BMS II
Equip Point Name Name
Read
Only
BACnet
Type:ID N2
Type
N2
ID
Lon SNVT
NAME
Lon SNVT
Lon
Direction
ModBus/
Unit
Address
2 06-Flow Sens
Temp
localsuptemp_2  AV:136
data
float
136 nvoMlxSupTmp2 inc count (9) Output (non-polled) 41003/2
2
07-Display Code dispcode_2  AV:137
data
float
137 nvoMlxDispCode2 inc count (9) Output (non-polled) 30001/2
2
11-Error Code errcode_2  AV:138
data
float
138 nvoMlxErrCode2 51 Output (non-polled) 40001/2
2
08-Unit Status unitstat_2  AV:139
data
float
139 nvoMlxStat2 inc count (9) Output (non-polled) 30002/2
2
09-Ret Flow Temp returntemp_2

AV:140
data
float
140 nvoMlxRetTmp2 inc count (9) Output (non-polled) 41004/2
Mlx Addr 3
3
01-Act Mod Lev boilerstate_3  AV:141
data
float
141 nvoMlxState3 inc count (9) Output (non-polled) 41009/3
3
02-Target Setpoint effectsetpt_3  AV:142
data
float
142 nvoMlxSetpt3 inc count (9) Output (non-polled) 41019/3
3 03-Req Outlet
Temp
setpt_3 AV:143
data
float
143 nviMlxSetptRq3 inc count (9) Input (non-polling) 41005/3
3
04-Net Direct Drive boilercmd_3 AV:144
data
float
144 nviMlxCmd3 inc count (9) Input (non-polling) 40002/3
3
05-Mod Lev In boilerload_3  AV:145
data
float
145 nvoMlxLoad3 inc count (9) Output (non-polled) 41201/3
3 06-Flow Sens
Temp
localsuptemp_3  AV:146
data
float
146 nvoMlxSupTmp3 inc count (9) Output (non-polled) 41003/3
3
07-Display Code dispcode_3  AV:147
data
float
147 nvoMlxDispCode3 inc count (9) Output (non-polled) 30001/3
3
11-Error Code errcode_3  AV:148
data
float
148 nvoMlxErrCode3 51 Output (non-polled) 40001/3
3
08-Unit Status unitstat_3  AV:149
data
float
149 nvoMlxStat3 inc count (9) Output (non-polled) 30002/3
3
09-Ret Flow Temp returntemp_3  AV:150
data
float
150 nvoMlxRetTmp3 inc count (9) Output (non-polled) 41004/3
Mlx Addr 4
4
01-Act Mod Lev boilerstate_16  AV:151
data
float
151 nvoMlxState16 inc count (9) Output (non-polled) 41009/16
