AERCO ProtoNode Gateway
User Manual
OMM-0080_0H AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 57 of 126
GF-129 Ph.: 800-526-0288 11/06/2014
Appendix B.2: AERCO Electronic Control System (ECS) Point
Definitions
Table B-2: AERCO Electronic Control System (ECS) Point Definitions
Point
Name
BAS Modbus
Data Address
GF-108, GF-
124, GF-114
Point Name
Reg.
Type
Modbus
Data
Address
(Hex/Dec.)
Units (Range)
Electric Valve (ECS) and SmartPlate
01-Cntl
Output
Signal
30004
OP (Control Output
Signal)
Input 0x0003 / 3 % (0 to 100)
02-Setpoint 30006 w.SP (Setpoint) Input 0x0005 / 5 °F (40 to 180)
03-RmSetpt 40027
Remote Input
Comms Access
parameter(Setpoint)
Holding 0x001A / 26 °F (40 to 180)
04-Outlet
Temp
30002
Top Value (Outlet
Temp)
Input 0x0001 / 1 °F (40 to 205)
05-FBk
Sensor
Temp
30290
Li1 (Feedback
Sensor Temp)
Input 0x0121 / 289 °F (40 to 180)
06-Over
Temp Alarm
30075
AL 1 (Over Temp
Alarm)
Input 0x004A / 74
Bit 0 = Alarm 1 State (0 = Safe 1 = Alarm).
Bit 1 = Alarm 2 State (0 = Safe 1 = Alarm).
Bit 2 = Alarm 3 State (0 = Safe 1 = Alarm).
Bit 3 = Alarm 4 State (0 = Safe 1 = Alarm).
Bit 4 = Manual Mode (0 = Auto 1 = Manual).
Bit 5 = Sensor Break (0 = Good PV 1 =
Sensor Broken.
Bit 6 = Loop Break (0 = Good closed loop 1
= Open Loop).
Bit 7 = Heater Fail (0 = No Fault 1 = Load
fault detected).
07-Flow
Rate
30291 Li2 (Flow) Input 0x0122 / 290 GPM
