AERCO ProtoNode Gateway
User Manual
Page 72 of 126 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0080_0H
11/06/2014 Ph.: 800-526-0288 GF-129
Table C-2: Eight C-Mores and One ACS/BMS II/BMS
Equip Point Name Name
Read
Only
BACnet
Type:ID
N2
Type
N2
ID
Lon SNVT
NAME
Lon SNVT Lon Direction
ModBus/
Unit Address
128 07-Num Boilers Fired blrfired_13  AV:37
data
float
127 nvoBlrsFired inc count (9) Output (non-polled) 30008/128
128
08-Num Boilers
Online
blronline_13  AV:38
data
float
128 nvoBlrsOnline inc count (9) Output (non-polled) 30009/128
128 09-Last Blr Fired blrlast_13  AV:39 data loat 129 nvoLastBlrFired inc count (9) Output (non-polled) 30017/128
128 10-Boiler 1 Status blr1stat_13  AV:40
data
float
130 nvoBlr1Stat inc count (9) Output (non-polled) 30018/128
128 11-Boiler 2 Status blr2stat_13  AV:41
data
float
131 nvoBlr2Stat inc count (9) Output (non-polled) 30019/128
128 12-Boiler 3 Status blr3stat_13  AV:48
data
float
132 nvoBlr3Stat inc count (9) Output (non-polled) 30020/128
128 13-Boiler 4 Status blr4stat_13  AV:1
data
float
133 nvoBlr4Stat inc count (9) Output (non-polled) 30021/128
128 14-Boiler 5 Status blr5stat_13  AV:2
data
float
134 nvoBlr5Stat inc count (9) Output (non-polled) 30022/128
128 15-Boiler 6 Status blr6stat_13  AV:3
data
float
135 nvoBlr6Stat inc count (9) Output (non-polled) 30023/128
128 16-Boiler 7 Status blr7stat_13  AV:4
data
float
136 nvoBlr7Stat inc count (9) Output (non-polled) 30024/128
128 17-Boiler 8 Status blr8stat_13  AV:5
data
float
137 nvoBlr8Stat inc count (9) Output (non-polled) 30025/128
128 18-Net Blr 1 Status blr9stat_13  AV:6
data
float
138 nvoNetBlr1Stat inc count (9) Output (non-polled) 30026/128
128 19-Net Blr 2 Status blr10stat_13  AV:7
data
float
139 nvoNetBlr2Stat inc count (9) Output (non-polled) 30027/128
128 20-Net Blr 3 Status blr11stat_13  AV:8
data
float
140 nvoNetBlr3Stat inc count (9) Output (non-polled) 30028/128
128 21-Net Blr 4 Status blr12stat_13  AV:9
data
float
141 nvoNetBlr4Stat inc count (9) Output (non-polled) 30029/128
128 22-Net Blr 5 Status blr13stat_13  AV:10
data
float
142 nvoNetBlr5Stat inc count (9) Output (non-polled) 30030/128
128 23-Net Blr 6 Status blr14stat_13  AV:11
data
float
143 nvoNetBlr6Stat inc count (9) Output (non-polled) 30031/128
