AERCO ProtoNode Gateway
User Manual
OMM-0080_0H AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 89 of 126
GF-129 Ph.: 800-526-0288 11/06/2014
Appendix C.5: ECS and SmartPlate
Table C-5: ECS and SmartPlate
Equip Point Name Name
Read
Only
BACnet
Type:ID N2
Type
N2
ID
Lon SNVT
NAME
Lon
SNVT
Lon Direction
ModBus/Unit
Address
E Valve Addr 29
29
01-Cntl Output
Signal
boilerstate_1  AV:11 data float 1 nvoEcsState29 inc count (9) Output (non-polled) 30004/29
29 02-Setpoint effectsetpt_1  AV:80 data float 2 nvoEcsSetpt29 inc count (9) Output (non-polled) 30006/29
29 03-RmSetpt rmsetpt_1 AV:81 data float 3 nviEcsSetptRq29 inc count (9) Input (non-polling) 40027/29
29 04-Outlet Temp localsuptemp_1  AV:84 data float 4 nvoEcsSupTmp29 inc count (9) Output (non-polled) 30002/29
29
05-FBk Sensor
Temp
localrettemp_1

AV:1 data float 5 nvoEcsRetTmp29 inc count (9) Output (non-polled) 30290/29
29
06-Over Temp
Alarm
unitstat_1  AV:86 data float 6 nvoEcsStat29 inc count (9) Output (non-polled) 30075/29
29 07-Flow Rate flowrate_1  AV:2 data float 7 nvoEcsFlow29 inc count (9) Output (non-polled) 30291/29
E Valve Addr 30
30
01-Cntl Output
Signal
boilerstate_2  AV:12 data float 8 nvoEcsState30 inc count (9) Output (non-polled) 30004/30
30 02-Setpoint effectsetpt_2  AV:3 data float 9 nvoEcsSetpt30 inc count (9) Output (non-polled) 30006/30
30 03-RmSetpt rmsetpt_2 AV:4 data float 10 nviEcsSetptRq30 inc count (9) Input (non-polling) 40027/30
30 04-Outlet Temp localsuptemp_2  AV:5 data float 11 nvoEcsSupTmp30 inc count (9) Output (non-polled) 30002/30
30
05-FBk Sensor
Temp
localrettemp_2  AV:6 data float 12 nvoEcsRetTmp30 inc count (9) Output (non-polled) 30290/30
30
06-Over Temp
Alarm
unitstat_2  AV:7 data float 13 nvoEcsStat30 inc count (9) Output (non-polled) 30075/30
30 07-Flow Rate flowrate_2  AV:8 data float 14 nvoEcsFlow30 inc count (9) Output (non-polled) 30291/30
E Valve Addr 31
