4-6 LiquiFlo AC Drive, Software Reference Version 6.4
To prevent unauthorized password use, a zero value (not the saved password value) is
displayed whenever this parameter is accessed.
Note that parameter values and the local keypad status are retained through a line dip
or power shutdown.
4.5 First Menu Parameters
The First Menu contains General parameters that are most commonly used for simple
applications. No password is required to access them. These parameters apply to
both vector and V/Hz programming and are described in detail in section 4.5.1.
4.5.1 First Menu General Parameter Descriptions (P.000 to P.006)
The selected drive control source is determined primarily by the value in P.000.
However, if P.000 = rE, then the REM/LOC input may toggle the control source
between the local keypad and the terminal strip. See P.007 (Terminal Strip Digital
Inputs Configure).
Depending on the control source selected, the AUTO/MAN key can be used to switch
between speed reference sources as shown in table 4.1.
P.000 Control Source
This parameter
selects the drive
control source.
The drive responds to
the reference,
forward/reverse,
run/jog, and start
commands (inputs)
only from the source
selected in this
parameter.
Parameter Range: LOCL = Local keypad/display
rE = Terminal strip remote inputs
OP = Option port
*
SErL = Serial port (CS3000 or OIM
**
)
* OP selection is not available if a network option board is not installed.
**
For more information about the Control and Configuration Software (CS3000), refer to instruction manual
D2-3348. For more information about the OIM (Operator Interface Module, M/N 2RK3000), refer to
instruction manual D2-3342.
Default Setting: LOCL
Parameter Type: Configurable
Refer also to parameters: P.007 Terminal Strip Digital Inputs Configure
P.008 Terminal Strip Speed Reference Source
P.063 Option Port: Network Reference Source
!
ATTENTION: In V/Hz regulation, if P.000 (Control Source) is set to OP
(Option Port), and P.062 is set to 1 (Hold Last Reference), and the drive
loses communication with the network, the drive will maintain the last
frequency command sent to it. Ensure that driven machinery, all
drive-train mechanisms, and application material are capable of safe
operation at the maximum operating speed of the drive. Failure to
observe this precaution could result in bodily injury.
