Using the Keypad/Display to Program, Monitor, and Control the Drive 3-5
This does not apply for the speed display. For the speed display, the FORWARD or
REVERSE LEDs indicate actual speed reference polarity.
3.4.2 Scaling the Manual Reference, Speed Display, and Reference
Display Using P.028
The values displayed for the manual reference, the output speed, and the selected
speed reference represent relative speed as opposed to always being displayed in
RPM. These values are scaled using P.028 (Speed Display Scaling). Refer to the
Speed Display Scaling parameter description in chapter 4 for more information.
Table 3.1 – Display Range Examples
Example
If the actual
number is... It will appear on the
display as...
And the SPEED LED
will...
A 1000.5 1000. Not flash
B -999 -999 Not flash
C -1000 1000 Flash
D -99.9 -99.9 Not flash
E -1000.5 1000. Flash
F -9.99 -9.99 Not flash
G -100.25 100.2 Flash
H -9.999 9.999 Flash
