Programming Reference 4-49
.
The option port trim reference is used as the outer control loop reference and/or the
speed trim reference (see the P.014 (Trim Reference Source) parameter description).
In V/Hz regulation, the trim reference represents speed in hertz scaled 0 to 4095 for 0
to Maximum Speed (P.004).
In vector regulation, the trim reference represents speed scaled 0 to 4095 for 0 to Top
Speed (U.017). When used for the outer control loop, the value should be scaled
based on the scaling of the selected feedback.
Refer to the following option board manuals:
• AutoMax Network Communication Option Board (D2-3308)
• ControlNet Network Communication Option Board (D2-3390)
• DeviceNet Network Communication Option Board (MAN0096-03)
•
PROFIBUS Interface Board (49’1355)
• Super Remote Meter Interface Board (D2-3341)
Refer to Appendix G for more information.
The display format is N.vvv, where N represents the option type (1 = RMI,
2 = AutoMax network or
PROFIBUS network, 4 = DeviceNet network, and 5 =
ControlNet network) and v represents the software version number.
For example, if 2.103 is displayed, it means the drive is using the AutoMax network
option and is running software version 1.03.
P.064 Option Port: Network Trim Reference Source
This parameter
specifies where the
drive gets its trim
reference when the
option port is
selected as the
control source
(P.000 = OP). Parameter Range: Option board-dependent. See option board
instruction manual.
Default Setting: 0
Parameter Type: Configurable
Refer also to parameters: P.063 Option Port: Network Reference Source
U.000 Torque Reference Source
P.065 Option Port: Type and Version
This parameter
displays the option
type and the software
version number of the
option board. Parameter Range: N/A
Default Setting: N/A
Parameter Type: Read only
Refer also to parameters: N/A
