D-4 LiquiFlo AC Drive, Software Reference Version 6.4
Second Menu Vector Parameters
* Parameter default is Power Module-dependent
Parameter
No. Parameter Name
USA
(P.049=USA)
EUROPE
(P.049=EUr)
JAPAN
(P.049=JPn)
U.000 Torque Reference Source 0 0 0
U.001 Encoder PPR 1024 2048 1024
U.002 Motor Poles 4 4 4
U.003 Motor Nameplate Base Frequency 60.0 50.0 60.0
U.004 Motor Nameplate Amps * * *
U.005 Motor Nameplate RPM * * *
U.006 Magnetizing Current * * *
U.007 Motor Nameplate Volts 460 380 460
U.008 Torque Self-Tune Enable OFF OFF OFF
U.009 Torque Self-Tune Result Read Only Read Only Read Only
U.012 Speed Regulator Proportional Gain * * *
U.013 Speed Regulator Integral Gain * * *
U.014 Torque Regulator Proportional Gain * 0.40 0.40
U.015 Torque Regulator Integral Gain * 200.0 200.0
U.016 Field Weakening Start RPM * * *
U.017 Motor Top Speed * * *
U.018 AC Line Volts 460 380 460
U.019 Flux Current Regulator Proportional Gain * .030 .030
U.020 Flux Current Regulator Integral Gain 50.0 50.0 50.0
U.021 Rotor Time Constant * 250 250
U.022 Motor Nameplate Horsepower * * *
U.023 Low DC Bus Fault Avoidance Enable OFF OFF OFF
U.024 High DC Bus Fault Avoidance Enable OFF OFF OFF
U.025 Zero Speed Hold Time 0.0 0.0 0.0
U.026 Current Compounding Gain 0.0 0.0 0.0
U.027 Inertia Compensation Gain 0.0 0.0 0.0
U.028 Losses Compensation Gain 0.0 0.0 0.0
U.030 SVC Slip Adjust 1.00 1.00 1.00
U.031 SVC Sync Direction OFF OFF OFF
U.032 SVC Flux Current Regulator Gain * * *
U.040 OCL Feedback Source 0 0 0
U.041 OCL Lead/Lag Select 0 0 0
U.042 OCL Lead/Lag Low Frequency 1.00 1.00 1.00
U.043 OCL Lead/Lag Ratio 10 10 10
U.044 OCL Reference Gain 1.000 1.000 1.000
U.045 OCL Proportional Gain 2.00 2.00 2.00
U.046 OCL Integral Gain 2.00 2.00 2.00
U.047 OCL Trim Range Percentage 0.0 0.0 0.0
U.048 OCL Proportional Trim Enable OFF OFF OFF
