H.0i8 – Rockwell Automation Liqui-Flo AC GP Vector Drive Version 6.4 User Manual
Page 29
Starting Up the Drive for Volts/Hertz Regulation
1-19
Step 6. Return to Monitor Mode
This step describes how to exit program mode and return to monitor mode.
Step 6.1 The display should now show the last parameter adjusted in step 5, H.018.
Step 6.2 Press the PROGRAM key twice to exit program mode.
The display returns to monitor mode
with speed displayed. The SPEED LED
is on and the PROGRAM LED is off.
