4-22 LiquiFlo AC Drive, Software Reference Version 6.4
For example, for an application using an output contactor, you can obtain a 0.5
second delay between a start assertion and the generation of motor voltage by setting
P.013 to 1. The delay will provide time for the contactor to close before motor voltage
is generated.
Selections 5 through 9 are available only if an optional RMI board is installed in the
drive. Refer to instruction manual D2-3341 for more information about the RMI board.
P.013 Output Relay Configuration
This parameter
specifies the type of
status indication
provided by the
output relay contacts
(terminals 28, 29, 30,
and 31 on the drive’s
terminal strip). Parameter Range: 0 = Output relay is energized to show state of active
fault (IET).
1 = Output relay is energized to show state of drive
running with 0.5 second delay added between a
start assertion and generation of motor voltage.
2 = Output relay is energized to show state of drive
running but without 0.5 second start delay.
3 = Output relay is energized to show state of
network communication active.
4 = Output relay is energized when all start
permissive conditions are met.
5 = Output relay is energized when one or more
alarms are active.
6 = Output relay is energized when no faults are
active.
Default Setting: 0
Parameter Type: Configurable
Refer also to parameters: N/A
P.014 Trim Reference Source
This parameter
specifies the source
for the trim reference.
Trim reference is
added to the speed
reference.
Refer to figure 4.3.
Parameter Range: 0 = No trim reference used
1 = Terminal strip analog input
2 = Option port trim reference register
3 = Maximum speed
4 = Torque current feedback (vector only)
5 = RMI board analog input
6 = RMI board frequency input
7 = Switched RMI board analog input or frequency
input
8 = RMI outer loop PI block (Mode 1)
9 = RMI outer loop PI block (Mode 2)
Default Setting: 0
Parameter Type: Configurable
Refer also to parameters: P.015 Trim Gain Percentage
