3-8 LiquiFlo AC Drive, Software Reference Version 6.4
3.6 Drive Status LEDs
The keypad contains eight LEDs that show the present drive status. Table 3.2
describes what each drive status LED means.
Table 3.2 – Drive Status LEDs
LED Status Meaning
RUNNING On Output power is being applied to the motor.
Off Output power is not being applied to the motor.
REMOTE On The drive is being controlled (START, RUN/JOG,
FORWARD/REVERSE, speed reference) from a source
other than the keypad.
Off The drive is being controlled from the keypad.
Flashing The network connection is lost.
JOG On Jog is selected.
Off Run is selected.
AUTO On The drive is receiving its speed reference from the
terminal strip input or network option.
Off The drive is receiving its speed reference from the local
keypad or serial port (OIM or CS3000), i.e., using a
manual reference.
FORWARD
1
1
If the speed reference is zero (0), pressing the FORWARD/REVERSE key (or toggling the FWD/REV
input) will not alter the state of the FORWARD or REVERSE LEDs.
Flashing The requested motor direction is forward; the actual
motor direction is reverse (REVERSE LED is on).
On The motor is running in the forward direction.
Off The motor direction is not forward.
REVERSE
1 Flashing The requested motor direction is reverse; the actual
motor direction is forward (FORWARD LED is on).
On The motor is running in the reverse direction.
Off The motor direction is not reverse.
PROGRAM On The keypad/display is in program mode.
Off The keypad/display is in monitor mode.
PASSWORD On Parameters cannot be modified from the keypad without
entering the correct password into P.051 (Programming
Disable). See section 4.4, Ensuring Program Security,
for more information.
Note that disabling program changes by means of P.051
does not prevent parameter changes being made from
the serial port or the network.
Off Parameters can be modified from the keypad.
