Default Parameter Settings D-1
A
PPENDIX
D
Default Parameter Settings
First and Second Menu General Parameters
Parameter
No. Parameter Name
USA
(P.049=USA)
EUROPE
(P.049=EUr)
JAPAN
(P.049=JPn)
P.000 Control Source LOCL LOCL LOCL
P.001 Accel Time 1 20.0 20.0 20.0
P.002 Decel Time 1 20.0 20.0 20.0
P.003 Minimum Speed P.048 = U-H
P.048 = UEC
5.0 Hz
150 RPM
5.0 Hz
150 RPM
5.0 Hz
150 RPM
P.004 Maximum Speed P.048 = U-H
P.048 = UEC
60.0 Hz
1722 RPM
50.0 Hz
1400 RPM
52.7 Hz
1500 RPM
P.005 Current Limit P.048 = U-H
P.048 = UEC
100
150 100
150 100
150
P.006 Second Menu Password Read Only Read Only Read Only
P.007 Terminal Strip Digital Inputs Configure 0 0 0
P.008 Terminal Strip Speed Reference Source 0 0 0
P.009 Terminal Strip Analog Input Offset 0 0 0
P.010 Terminal Strip Analog Input Gain 1.000 1.000 1.000
P.011 Terminal Strip Analog Input Configure 0 0 0
P.012 Terminal Strip Analog Output Source 0 0 0
P.013 Output Relay Configuration 0 0 0
P.014 Trim Reference Source 0 0 0
P.015 Trim Gain Percentage 0.0 0.0 0.0
P.016 Draw Gain Percentage 0.0 0.0 0.0
P.017 Accel Time 2 20.0 20.0 20.0
P.018 Decel Time 2 20.0 20.0 20.0
P.019 S-Curve Enable P.048 = U-H
P.048 = UEC ON
OFF
ON
ON
ON
OFF
P.020 Jog Speed Reference P.048 = U-H
P.048 = UEC
5.0 Hz
150 RPM
5.0 Hz
150 RPM
5.0 Hz
150 RPM
P.021 Jog Ramp Accel Time 20.0 20.0 20.0
P.022 Jog Ramp Decel Time 20.0 20.0 20.0
P.023 MOP Accel/Decel Time 20.0 20.0 20.0
P.024 MOP Reset Configuration 0 0 0
P.025 Stop Type 0 0 0
P.026 Function Loss Response 0 0 1
P.027 Forward/Reverse Configuration 0 0 0
