Programming Reference

4-33

The presets are configured using parameters P.007 and P.008. P.008 must be set to
values of 2 through 7 for preset speeds. See table 4.4 and figure 4.6.

Each speed is selected using external switches connected to terminals 17, 18, and 19
on the Regulator board.

The presets may also be selected using the Remote Meter Interface (RMI) board.
Refer to the RMI board instruction manual (D2-3341) for more information. If you have
installed an optional RMI board in your drive, refer to Appendix E for more information.

P.031 to P.038 Preset Speed 1 through Preset Speed 8

These parameters
allow the setting of up
to eight different
preset speeds.

Parameter Range:

Minimum Speed (P.003) to Maximum Speed (P.004)

Default Setting:

5.0 Hz (V/Hz)
150 RPM (vector)

Parameter Type:

Tunable

Refer also to parameters:

P.007 Terminal Strip Digital Inputs Configure
P.008 Terminal Strip Speed Reference Source

Table 4.4 – Preset Speed Digital Inputs

Digital Inputs (Terminals)

Selected

Speed Reference

8 (17)

7 (18)

6 (19)

0 (open)

P.031 or analog input (see P.008,

selections 5, 6, and 7)

0 (open)

1 (closed)

P.032

0 (open)

1 (closed)

0 (open)

P.033

0 (open)

1 (closed)

P.034

1 (closed)

0 (open)

P.035

1 (closed)

0 (open)

1 (closed)

P.036

1 (closed)

0 (open)

P.037

1 (closed

1 (closed)

P.038
