Adjust screen parameters, Filename font file exit, Panelview 300 micro terminal screen setup – Rockwell Automation 2711 Standard PanelView Operator Terminal User Manual User Manual
Page 90: Filename, Font file, Exit
90
Publication 2711-UM014G-EN-P - September 2008
Chapter 3 Configuring the Terminal
Communication Port (P#.xxx, for example, P0.485 or P1.232)
Screen Size (SS5.5, SS6.0, SS9.0, SS10.0, SS14.0)
Filename
Displays the name of the active application file. If the application file
exists but is invalid, the file name appears as ********.
•
Bytes Used displays the number of bytes used by the loaded
application.
•
Bytes Free displays the number of bytes available.
Font File
Displays the name of the external font file used by the application.
Exit
Returns to the Configuration Mode menu.
Adjust Screen Parameters
Select Screen Setup from the Configuration Mode menu to adjust
settings of the terminal display. Changes take effect immediately.
PanelView 300 Micro Terminal Screen Setup
The PanelView 300 Micro terminal backlight is always on and intensity
is not adjustable.
SCREEN SETUP
F1 Contrast
F4 EXIT
6
F3 MORE
F2 Mode
Normal
SCREEN SAVER
F1 Mode
F4 EXIT
Off
F2 Timeout
5 min.
SCREEN SETUP
F1 Reset Video
F4 EXIT
F3 MORE
F3 MORE
