50 Publication 2711-UM014G-EN-P - September 2008
Chapter 1 Terminal Overview
Configuration Mode Menu You can configure terminal functions from the Configuration Mode
menu. These functions include how to:
•
select a language.
•
upload/download applications with a memory card.
•
set or display serial communication parameters.
•
select preset values.
•
obtain terminal and application information.
•
adjust screen parameters.
•
set time and date.
•
set printer parameters (for terminals with an RS-232 printer
port).
•
return to run mode.
Chapter 3 describes how to enter configuration mode and operations
you can perform by using the Configuration Mode menu.
Terminal Messages Terminal messages display:
•
status of an operation.
•
minor faults, errors, or numeric entry mistakes.
•
operator prompts.
Appendix B describes terminal messages and provides a list of
recommended actions.
IMPORTANT
The keypad is designed for finger or gloved finger operation.
The touch screen may be operated with a finger, gloved finger,
or with a touch screen plastic stylus device with a minimum tip
radius of 1 mm (0.040 in) to prevent damage to the touch
screen. Using any other object or tool may damage the keypad
or touch screen.
