Chapter 12 Terminal Connections
Supported Controllers
The remote I/O terminal connects to any Allen-Bradley 1771 remote
I/O link. Applicable host controllers include almost all Allen-Bradley
PLCs, computers, VME controllers, and DEC Q-Bus controllers with a
remote I/O scanner module. New PLC product releases that support
1771 remote I/O will also work with PanelView.
When connecting a PanelView terminal to a controller refer to the
user manual for your controller or scanner module for connection
diagrams and any remote I/O limitations. The table below provides a
summary of possible connections.
Controller
Scanner
Comments
ControlLogix
1756-DHRIO
Connect PanelView terminals through the 1756-DHRIO module.
PLC-5/11, 5/15
(1)
,
5/20, 5/25,
5/30, 5/60, 5/80,
5/250
PLC Integral 1771-SN
Connect PanelView terminals directly to the remote I/O port (scanner
mode). Connect PanelView terminals through the 1771-SN
subscanner module.
PLC-5/10, 5/12
1771-SN
Connect PanelView terminals through the 1771-SN subscanner
module.
PLC-2
1771-SN or 1772-SD2
(2)
Connect PanelView terminals to the PLC-2 family of processors
through a 1771-SN I/O subscanner module.
PLC-3 and
PLC-3/10
None
PLC-3/10
remote I/O Scanner
(3)
Connect PanelView terminals directly to a PLC-3.
Connect PanelView terminals to the PLC-3/10 through the remote I/O
scanner.
SLC-5/02, 5/03, 5/04,
5/05
1747-SN
Connect PanelView terminals through the 1747-SN subscanner
module. Each module provides an additional remote I/O link for up to
4 racks.
Important: Only Series B and later versions of the 1747-SN
subscanner support block transfers.
IBM PC
6008-SI
6008-SI I/O scanner is compatible with IBM PC or compatible
computers. The scanner provides a computer access to the 1771
remote I/O link.
VME
6008-SV
6008-SV I/O scanner provides access to the 1771 remote I/O link for
VME controllers.
DEC Q-BUS
6008-SQ
6008-SQ I/O scanner provides access to the 1771 remote I/O link for
DEC Q-BUS controllers.
(1)
If using a PLC-5/15 with partial rack addressing and block transfers, you must use Series B, Rev. J or later.
(2)
If using a 1772-SD2 Remote Scanner/Distribution Panel, use revision 3 or later.
(3)
If using a 1775-S4A Remote Scanner/Distribution Panel, user Series B or later.
