18 Publication 2711-UM014G-EN-P - September 2008
Chapter 1 Terminal Overview
Color and Grayscale Terminals
Color terminals support a fixed palette of 32 standard EGA colors.
Grayscale terminals support a fixed palette of four colors (shades of
gray). All color in an application is defined when the application is
created. Colors are not selectable at the terminal.
PanelView 300 Monochrome Terminals
The PanelView 300 terminal is only available with 24V DC input
power.
PanelView 300 Micro Monochrome Terminals
The PanelView 300 Micro terminal is available only with 24V DC input
power and does not have a printer port. The PV300 Micro terminal
contains a single RS-232 communication port which supports either
DF1 or DH485 communication protocols as specified in the table
below.
Operator
Input Communication Port Printer Port
RS-232 Catalog
Number
DH-485 RS-232
(DH-485) DeviceNet RS-232
(DF1)
Keypad x 2711-K3A2L1
x 2711-K3A5L1
x x 2711-K3A10L1
x 2711-K3A17L1
Operator
Input Communication Port Catalog
Number
DH-485 DF1
Keypad x 2711-M3A19L1
x 2711-M3A18L1
