Publication 2711-UM014G-EN-P - September 2008 33
Terminal Overview Chapter 1
# Feature Description
1 Power Connection Terminals Connects to external DC power source.
2 Sealing Gasket Seals the front of the terminal to an enclosure or panel.
3 FAULT Status (Red) Indicator Indicates firmware or hardware faults.
4 COMM Status (Green) Indicator Indicates when communication is occurring.
5 Nameplate Label Provides product information.
6 Memory Card Slot Accepts a memory card which stores applications.
7 Reset Button Resets the terminal.
8 Access Cover
Provides access to the replaceable backlight lamp.
(1)
9 Backlight Lamp
Light source for the display backlight.
(1)
10 DH-485 Communication Port Connects to an SLC or MicroLogix controller, DH-485 network, or Wallmount Power
Supply (Cat. No. 1747-NP1).
11 DH-485 Programming Connector Connects to a Personal Computer Interface Converter (Cat. No. 1747-PIC) for
transferring applications. Also connects to an SLC programmer, such as the
Hand-held Terminal (Cat. No. 1747-PT1).
12 RS-232 (DH-485) Communication Port Connects to the Channel 0 port of an SLC 5/03, 5/04, or 5/05 for point-to-point
DH-485 communication. Connects to a MicroLogix controller through an AIC+ Link
Coupler. Also connects to the RS-232 serial port of a computer for transferring
applications.
13 Remote I/O Port Connects to a scanner or sub-scanner on a remote I/O network.
14 DH+ Communication Port Connects to a PLC-5, SLC 5/04, or ControlLogix controller on a DH+ link.
15 DeviceNet Connector Connects to a DeviceNet network.
16 ControlNet Connector Connects to a ControlLogix controller (with 1756-CNB module) or PLC-5 on a
ControlNet network.
17 RS-232 (DF1) Communication Port Connects to a PLC, SLC, or MicroLogix controller with a DF1 port.
18 Ethernet Connector Connects to a PLC-5E or SLC 5/05 controller, or a ControlLogix, MicroLogix, FlexLogix
or CompactLogix (with appropriate bridge module) on an EtherNet/IP network.
19 RS-232 Printer/File Transfer Port Connects to a printer.
On remote I/O, DH+, DF1, DeviceNet, EtherNet/IP, or ControlNet terminals, this port
also connects to the RS-232 port of a computer for transferring applications.
The RS-232 port on the DH-485 or RS-232 (DH-485) terminal is used to connect a
printer but not for file transfers.
(1)
Series B and later PanelView 550 Touch Terminals have an integrated LED backlight. This backlight is non-replaceable.
