234 Publication 2711-UM014G-EN-P - September 2008
Appendix A Specifications
Character Sizes (Pixel size = 0.48 x 0.48 mm)
PanelView 300 Terminal
Size in Pixels
width x height) Characters/Row Maximum Rows Dimensions in mm
Width x Height
4 x 6 31 10 1.9 x 2.9
6 x 8 20 7 2.9 x 3.8
6 x 16 20 3 2.9 x 7.7
6 x 24 20 2 2.9 x 11.5
12 x 8 10 7 5.8 x 3.8
12 x 16 10 3 5.8 x 7.7
12 x 24 10 2 5.8 x 11.5
18 x 8 6 7 8.6 x 3.8
18 x 16 6 3 8.6 x 7.7
18 x 24 6 2 8.6 x 11.5
Electrical
DC Power
Supply Voltage Limits
Power Consumption
18…32V DC (24V DC nominal), Class 2 Power Supply
6 Watts (0.25 Amps at 24V DC)
Mechanical
Enclosure NEMA Type 12/13, 4X (Indoor use only),
IP54, IP65
Status Indicators
COMM
Fault
Green
Red
Weight 673 g (1.48 lb)
Dimensions
mm
in
197 (H) x 140 (W) x 82 (D)
7.76 (H) x 5.53 (W) x 3.21 (D)
Installed Depth 69 mm (2.73 in.)
122.4 mm (4.82 in.) with memory card
retainer
216 mm (8.5 in.) with memory card retainer
and clearance to insert and remove memory
card
