Publication 2711-UM014G-EN-P - September 2008 233
Appendix
A
Specifications
PanelView 300 Micro
Terminal
Electrical
DC Power
Supply Voltage Limits
Power Consumption
11…30V DC (24V nominal), Class 2 Power Supply
2.5 W maximum (0.105A @24V DC)
Mechanical
Enclosure NEMA Type 12/13, 4X (Indoor use only),
IP54, IP65
Weight 284 g (10 oz.)
Dimensions
mm
inches
133 (H) x 112 (W) x 48 (D)
5.23 (H) x 4.38 (W) x 1.87 (D)
Installed Depth 35mm (1.39 in.)
Display
Type Liquid Crystal Display (LCD) with integral
LED backlight (100,000 hour life)
Size 73 mm (w) x 42 mm (h)
2.87 in. (w) x 1.67 in. (h)
Pixels 128 x 64
Terminal Memory
Total Application Flash Memory 240K bytes (application screens)
Environment
Operating Temperature 0…55
°
C (32…131
°
F)
Storage Temperature -20…85
°
C (-4…188
°
F)
Relative Humidity (noncondensing) 5…95% at 0…55
°
C (32…131
°
F)
Heat Dissipation 2.5 Watts (8.5 BTU/Hour)
Shock (operating, nonoperating) 30 g/50 g
Vibration (operating) 2 g up to 2,000 Hz
