Rockwell Automation 2711 Standard PanelView Operator Terminal User Manual User Manual
Page 54
54
Publication 2711-UM014G-EN-P - September 2008
Chapter 1 Terminal Overview
PanelView File Transfer Utility
Power Supply and Link Couplers
The following items are available for all PanelView terminals.
1761-CBL-PM02
2 m (6.5 ft) cable connects an RS-232 terminal to an AIC+ (Port2) through a null modem adapter.
2711-CBL-PM05
5 m programming cable with a D-shell and mini DIN connector.
2711-CBL-PM10
10 m programming cable with a D-shell and mini DIN connector.
Cat. No.
Description
Cat. No.
Description
2711-ND7
Transfers .PVA files between a PanelView terminal and a computer
running Windows.
Cat. No.
Description
1747-NP1
Wallmount power supply provides power for DH-485 communication
when an SLC controller or network is not connected.
1747-AIC
AIC Link Coupler links devices on a DH-485 network.
1761-NET-AIC
AIC+ Advanced Interface Converter links devices on a DH-485
network including MicroLogix.
1761-NET-DNI
DeviceNet Interface links DF1 PanelViews on a DeviceNet network.
1761-NET-ENI
Ethernet Interface links DF1 or Ethernet devices on an EtherNet/IP
network.
