Publication 2711-UM014G-EN-P - September 2008 41
Terminal Overview Chapter 1
# Feature Description
1 Function Keys (F1…F16) Use the function keys on keypad terminals to initiate functions on the terminal
display. These keys may have custom legends.
2 Cursor Keys Use the cursor keys to move the cursor in displayed lists, to select a numeric entry
object or to enter configuration mode.
3 Numeric Entry Keys 0…9 - Enters numeric values.
. Enters a decimal point.
- Enters a negative value.
←
Clears entered digits or cancels the scratchpad.
↵
Stores an entered value.
4 Keypad Terminal Display On keypad terminals, initiate the function of a displayed object, such as an ON or
OFF push button, by pressing a function key (F1…F16).
5 Touch Screen Terminal Display On touch screen terminals, initiate the function of a displayed object, such as an
ON or OFF push button, by touching the screen object. Each interactive screen
object occupies one or more of 384 cells.
6 Touch Cells (Touch Screen terminal) The 384 touch cells (24 columns x 16 rows) let you initiate functions by touching
the screen. Interactive screen objects are aligned with touch cells when the
application is created.
